• Stud type cam follower
• Crowned outside diameter
• Needle rolling elements
• Hex hole
• LUBRI-DISC® seal

Dimensions

Threads	3/4-16
Roller Diameter (in)	1.25 in
Stud Diameter (in)	0.75 in
Stud Length (in)	1.25 in
Lubrication Fitting Size (mm)	3/16 mm
Minimum Thread Length (in)	0.63 in
Roller Width (in)	0.75 in
Lubrication Fitting Size (in)	3/16 in
Oil Hole Diameter (in)	0.094 in
Oil Hole Center (in)	0.3125 in
Weight (kg)	0.18 kg

Technical Specifications

Hex/Slot	Hex Hole
Sealing	Sealed
Limiting Speed	3,100
O.D. Configuration	Crowned
Series	Inch CAMROL®
Adjustment	None
Rolling Element	Needle Roller - Full Complement
Material	Bearing Steel, Black Oxide Finish
Platform	CAMROL®
Dynamic Load Rating (lb)	3,930 lb
Static Load Rating	8,500
Tolerance Class	P0 Equivalent
Stud Type	Heavy Stud
Roller Shape	Crowned
Lubrication Hole Location	Stud side
Ability to Relubricate	No
Clamping Torque (in-lbf)	1,250 lbs

General Specifications

UPC	726166034788
Weight	0.39 LB
Packaged Length	1.50 IN
Packaged Width	1.75 IN
Packaged Height	2.18 IN
HTC	8482.40.0000
Country of Origin	Mexico
