• Heavy duty stud type cam follower
• Cylindrical outside diameter
• Full complement cylindrical rolling elements
• Hex hole

Dimensions

Threads	3/4-16
Roller Diameter (in)	1.75 in
Hex Socket (in)	0.3125 in
Stud Diameter (in)	0.75 in
Stud Length (in)	1.75 in
Roller Width (in)	1 in
Minimum Thread Length (in)	0.88 in
Weight (kg)	0.38 kg

Technical Specifications

Sealing	Sealed
Rolling Element	Cylindrical Roller
Series	Heavy Duty Inch CAMROL®
Hex/Slot	Hex Hole
Adjustment	None
Limiting Speed	2,200
Dynamic Radial Rating	6,650
O.D. Configuration	Cylindrical
Material	Bearing Steel, Black Oxide Finish
Static Load Rating	5,700
Roller Shape	Cylindrical
Dynamic Load Rating (lb)	6,650 lb
Tolerance Class	P0 Equivalent
Platform	HEAVY-DUTY CAMROL®
Stud Type	Standard Stud
Clamping Torque (in-lbf)	1,250 lbs
Ability to Relubricate	No

General Specifications

UPC	726166119201
Weight	0.84 LB
Packaged Length	2.00 IN
Packaged Width	2.00 IN
Packaged Height	2.87 IN
HTC	8482.50.0000
Country of Origin	Mexico
