• Heavy duty stud type cam follower
• Crowned outside diameter
• Full complement cylindrical rolling elements
• Hex hole

Dimensions

Threads	1-14
Crown Radius	30
Roller Diameter (in)	2.5 in
Roller Width (in)	1.5 in
Minimum Thread Length (in)	1.13 in
Hex Socket (in)	0.5 in
Stud Length (in)	2.25 in
Stud Diameter (in)	1 in
Weight (kg)	1.08 kg

Technical Specifications

Adjustment	None
Series	Heavy Duty Inch CAMROL®
Dynamic Radial Rating	14,000
Limiting Speed	1,100
O.D. Configuration	Crowned
Rolling Element	Cylindrical Roller
Sealing	Sealed
Hex/Slot	Hex Hole
Material	Bearing Steel, Black Oxide Finish
Roller Shape	Crowned
Platform	HEAVY-DUTY CAMROL®
Stud Type	Standard Stud
Dynamic Load Rating (lb)	14,000 lb
Static Load Rating	9,790
Tolerance Class	P0 Equivalent
Ability to Relubricate	No
Clamping Torque (in-lbf)	2,250 lbs

General Specifications

UPC	726166119386
Weight	2.37 LB
Packaged Length	2.81 IN
Packaged Width	2.81 IN
Packaged Height	3.93 IN
HTC	8482.50.0000
Country of Origin	Mexico
