• Heavy duty stud type cam follower
• Crowned outside diameter
• Full complement cylindrical rolling elements
• Hex hole

Dimensions

Threads	5/8-18
Crown Radius	20
Roller Diameter (in)	1.5 in
Minimum Thread Length (in)	0.75 in
Roller Width (in)	0.875 in
Stud Length (in)	1.5 in
Hex Socket (in)	0.3125 in
Stud Diameter (in)	0.625 in
Weight (kg)	0.23 kg

Technical Specifications

Series	Heavy Duty Inch CAMROL®
Dynamic Radial Rating	5,000
Adjustment	None
Sealing	Sealed
Rolling Element	Cylindrical Roller
Hex/Slot	Hex Hole
Limiting Speed	2,500
O.D. Configuration	Crowned
Material	Bearing Steel, Black Oxide Finish
Tolerance Class	P0 Equivalent
Static Load Rating	4,100
Platform	HEAVY-DUTY CAMROL®
Roller Shape	Crowned
Dynamic Load Rating (lb)	5,000 lb
Stud Type	Standard Stud
Lubrication Hole Location	None
Clamping Torque (in-lbf)	650 lbs
Ability to Relubricate	No

General Specifications

UPC	726166119812
Weight	0.50 LB
Packaged Length	1.68 IN
Packaged Width	1.68 IN
Packaged Height	2.62 IN
HTC	8482.50.0000
Country of Origin	Mexico
