• Yoke type cam follower
• Cylindrical outside diameter
• Needle rolling elements
• LUBRI-DISC® seal

Dimensions

Roller Diameter (in)	7 in
Bore Diameter (in)	2.75 in
Endplate Diameter (in)	5.19 in
Roller Width (in)	3.75 in
Oil Hole Diameter (in)	0.188 in
Overall Width (in)	3.875 in
Minimum Boss Diameter (in)	3.875 in
Weight (kg)	15.02 kg

Technical Specifications

Sealing	Sealed
O.D. Configuration	Cylindrical
Series	Inch CAMROL®
Rolling Element	Needle Roller - Full Complement
Limiting Speed	400
Material	Bearing Steel, Black Oxide Finish
Tolerance Class	P0
Roller Shape	Cylindrical
Platform	CAMROL®
Dynamic Load Rating (lb)	75,380 lb
Static Load Rating	213,860
Roller Material	Chrome Steel
Lubrication Hole Location	Inner Ring
Adjustment	None
Enclosure	2 Seals
Operating Temperature Range (F)	-20 to 250 °F °F
Ability to Relubricate	Yes

General Specifications

UPC	726166058395
Weight	33.11 LB
Packaged Length	8.12 IN
Packaged Width	8.18 IN
Packaged Height	4.37 IN
HTC	8482.50.0000
Country of Origin	Mexico
