• Yoke type cam follower
• Cylindrical outside diameter
• Needle rolling elements
• LUBRI-DISC® seal

Dimensions

Roller Diameter (in)	0.875 in
Bore Diameter (in)	0.25 in
Roller Width (in)	0.5 in
Oil Hole Diameter (in)	0.094 in
Endplate Diameter (in)	0.61 in
Overall Width (in)	0.5625 in
Minimum Boss Diameter (in)	0.5 in
Weight (kg)	0.04 kg

Technical Specifications

Limiting Speed	5,400
Series	Inch CAMROL®
O.D. Configuration	Cylindrical
Rolling Element	Needle Roller - Full Complement
Sealing	Sealed
Material	Bearing Steel, Black Oxide Finish
Tolerance Class	P0
Platform	CAMROL®
Dynamic Load Rating (lb)	1,660 lb
Roller Shape	Cylindrical
Static Load Rating	4,130
Roller Material	Chrome Steel
Lubrication Hole Location	Inner Ring
Adjustment	None
Enclosure	2 Seals
Ability to Relubricate	Yes
Operating Temperature Range (F)	-20 to 250 °F °F

General Specifications

UPC	726166056339
Weight	0.09 LB
Packaged Length	1.75 IN
Packaged Width	1.00 IN
Packaged Height	1.75 IN
HTC	8482.40.0000
Country of Origin	Mexico
