• Yoke type cam follower
• Cylindrical outside diameter
• Needle rolling elements
• LUBRI-DISC® seal

Dimensions

Bore Diameter (in)	2.25 in
Roller Diameter (in)	6 in
Endplate Diameter (in)	4.47 in
Oil Hole Diameter (in)	0.188 in
Overall Width (in)	3.375 in
Minimum Boss Diameter (in)	3.375 in
Roller Width (in)	3.25 in
Weight (kg)	9.63 kg

Technical Specifications

Limiting Speed	475
O.D. Configuration	Cylindrical
Sealing	Sealed
Rolling Element	Needle Roller - Full Complement
Series	Inch CAMROL®
Material	Bearing Steel, Black Oxide Finish
Static Load Rating	160,900
Tolerance Class	P0
Dynamic Load Rating (lb)	60,000 lb
Roller Shape	Cylindrical
Platform	CAMROL®
Lubrication Hole Location	Inner Ring
Roller Material	Chrome Steel
Adjustment	None
Enclosure	2 Seals
Ability to Relubricate	Yes
Operating Temperature Range (F)	-20 to 250 °F °F

General Specifications

UPC	726166058364
Weight	21.23 LB
Packaged Length	6.12 IN
Packaged Width	6.12 IN
Packaged Height	4.25 IN
HTC	8482.50.0000
Country of Origin	Mexico
