• Yoke type cam follower
• Cylindrical outside diameter
• Needle rolling elements

Dimensions

Bore Diameter (in)	0.25 in
Roller Diameter (in)	0.75 in
Minimum Boss Diameter (in)	0.5 in
Roller Width (in)	0.5 in
Oil Hole Diameter (in)	0.094 in
Overall Width (in)	0.5625 in
Endplate Diameter (in)	0.61 in
Weight (kg)	0.03 kg

Technical Specifications

Limiting Speed	6,400
Sealing	Unsealed
Rolling Element	Needle Roller - Full Complement
Series	Inch CAMROL®
O.D. Configuration	Cylindrical
Material	Bearing Steel, Black Oxide Finish
Roller Shape	Cylindrical
Tolerance Class	P0
Platform	CAMROL®
Dynamic Load Rating (lb)	1,660 lb
Static Load Rating	4,130
Adjustment	None
Enclosure	Open
Ability to Relubricate	Yes

General Specifications

UPC	726166056087
Weight	0.07 LB
Packaged Length	1.75 IN
Packaged Width	1.00 IN
Packaged Height	1.75 IN
HTC	8482.40.0000
Country of Origin	Mexico
