• Yoke type cam follower
• Cylindrical outside diameter
• Needle rolling elements
• LUBRI-DISC® seal

Dimensions

Bore Diameter (in)	1 in
Roller Diameter (in)	3.25 in
Minimum Boss Diameter (in)	1.75 in
Oil Hole Diameter (in)	0.125 in
Overall Width (in)	1.8125 in
Roller Width (in)	1.75 in
Endplate Diameter (in)	2.13 in
Weight (kg)	1.6 kg

Technical Specifications

Sealing	Sealed
Series	Inch CAMROL®
Limiting Speed	880
Rolling Element	Needle Roller - Full Complement
O.D. Configuration	Cylindrical
Material	Bearing Steel, Black Oxide Finish
Static Load Rating	49,820
Roller Shape	Cylindrical
Tolerance Class	P0
Dynamic Load Rating (lb)	15,720 lb
Platform	CAMROL®
Adjustment	None
Enclosure	2 Seals
Ability to Relubricate	Yes

General Specifications

UPC	726166058098
Weight	3.52 LB
Packaged Length	3.62 IN
Packaged Width	2.12 IN
Packaged Height	3.62 IN
HTC	8482.40.0000
Country of Origin	Mexico
