• Yoke type cam follower
• Cylindrical outside diameter
• Needle rolling elements
• LUBRI-DISC® seal
• Corrosion resistant

Dimensions

Bore Diameter (in)	0.375 in
Roller Diameter (in)	1.25 in
Overall Width (in)	0.8125 in
Endplate Diameter (in)	0.88 in
Minimum Boss Diameter (in)	0.766 in
Oil Hole Diameter (in)	0.094 in
Roller Width (in)	0.75 in
Weight (kg)	0.1 kg

Technical Specifications

Rolling Element	Needle Roller - Full Complement
Series	CRES CAMROL®
Sealing	Sealed
O.D. Configuration	Cylindrical
Limiting Speed	3,100
Material	440C Stainless Steel
Tolerance Class	P0
Platform	CAMROL®
Dynamic Load Rating (lb)	3,530 lb
Static Load Rating	7,700
Roller Shape	Cylindrical
Roller Material	Stainless Steel
Lubrication Hole Location	Inner Ring
Adjustment	None
Enclosure	2 Seals
Operating Temperature Range (F)	-20 to 250 °F °F
Ability to Relubricate	Yes

General Specifications

UPC	726166118341
Weight	0.21 LB
Packaged Length	1.75 IN
Packaged Width	1.00 IN
Packaged Height	1.75 IN
HTC	8482.40.0000
Country of Origin	Mexico
