• Stud type cam follower
• Cylindrical outside diameter
• Needle rolling elements
• Hex hole
• LUBRI-DISC® seal
• Eccentric configuration

Dimensions

Threads	1 1/2-12
Roller Diameter (in)	4 in
Minimum Thread Length (in)	1.5 in
Hex Socket (in)	0.75 in
Eccentricity (in)	0.06 in
Stud Length (in)	3.5 in
Stud Diameter (in)	1.4 in
Lubrication Fitting Size (in)	0.25 in
Bushing Diameter (in)	2 in
Roller Width (in)	2.25 in
Lubrication Fitting Size (mm)	0.25 mm
Weight (kg)	4.5 kg

Technical Specifications

Limiting Speed	700
Hex/Slot	Hex Hole
O.D. Configuration	Cylindrical
Series	Inch CAMROL®
Sealing	Sealed
Adjustment	Eccentric Bushing
Dynamic Radial Rating	22,800
Rolling Element	Needle Roller - Full Complement
Material	Bearing Steel, Black Oxide Finish
Static Load Rating	25,000
Dynamic Load Rating (lb)	29,985 lb
Platform	CAMROL®
Stud Type	Standard Stud with Eccentric Bushing
Roller Shape	Cylindrical
Tolerance Class	P0 Equivalent
Clamping Torque (in-lbf)	5,000 lbs
Ability to Relubricate	Yes

General Specifications

UPC	726166040260
Weight	9.91 LB
Packaged Length	4.00 IN
Packaged Width	4.00 IN
Packaged Height	6.00 IN
HTC	8482.40.0000
Country of Origin	Mexico
