• Stud type cam follower
• Cylindrical outside diameter
• Needle rolling elements
• Hex hole
• LUBRI-DISC® seal
• Eccentric configuration

Dimensions

Threads	1-14
Roller Diameter (in)	2.75 in
Stud Diameter (in)	1 in
Hex Socket (in)	0.5 in
Lubrication Fitting Size (in)	0.1875 in
Minimum Thread Length (in)	1.13 in
Lubrication Fitting Size (mm)	0.1875 mm
Stud Length (in)	2.25 in
Roller Width (in)	1.5 in
Eccentricity (in)	0.03 in
Bushing Diameter (in)	1.375 in
Weight (kg)	1.38 kg

Technical Specifications

Limiting Speed	1,050
O.D. Configuration	Cylindrical
Dynamic Radial Rating	11,720
Adjustment	Eccentric Bushing
Series	Inch CAMROL®
Rolling Element	Needle Roller - Full Complement
Sealing	Sealed
Hex/Slot	Hex Hole
Material	Bearing Steel, Black Oxide Finish
Static Load Rating	10,300
Dynamic Load Rating (lb)	11,720 lb
Platform	CAMROL®
Tolerance Class	P0 Equivalent
Stud Type	Standard Stud with Eccentric Bushing
Roller Shape	Cylindrical
Clamping Torque (in-lbf)	2,250 lbs
Ability to Relubricate	Yes

General Specifications

UPC	726166038847
Weight	3.04 LB
Packaged Length	2.81 IN
Packaged Width	2.81 IN
Packaged Height	3.93 IN
HTC	8482.40.0000
Country of Origin	Mexico
