• Stud type cam follower
• Cylindrical outside diameter
• Needle rolling elements
• Hex hole
• LUBRI-DISC® seal
• Eccentric configuration

Dimensions

Threads	3/4-16
Roller Diameter (in)	1.875 in
Hex Socket (in)	0.3125 in
Eccentricity (in)	0.03 in
Lubrication Fitting Size (in)	0.1875 in
Stud Diameter (in)	0.75 in
Minimum Thread Length (in)	0.88 in
Lubrication Fitting Size (mm)	0.1875 mm
Roller Width (in)	1 in
Bushing Diameter (in)	1 in
Stud Length (in)	1.75 in
Weight (kg)	0.45 kg

Technical Specifications

Limiting Speed	2,000
O.D. Configuration	Cylindrical
Adjustment	Eccentric Bushing
Dynamic Radial Rating	6,385
Series	Inch CAMROL®
Sealing	Sealed
Rolling Element	Needle Roller - Full Complement
Hex/Slot	Hex Hole
Material	Bearing Steel, Black Oxide Finish
Static Load Rating	6,000
Platform	CAMROL®
Dynamic Load Rating (lb)	6,385 lb
Roller Shape	Cylindrical
Stud Type	Standard Stud with Eccentric Bushing
Tolerance Class	P0 Equivalent
Clamping Torque (in-lbf)	1,250 lbs
Ability to Relubricate	Yes

General Specifications

UPC	726166037024
Weight	1.00 LB
Packaged Length	2.00 IN
Packaged Width	2.00 IN
Packaged Height	2.87 IN
HTC	8482.40.0000
Country of Origin	Mexico
