• Stud type cam follower
• Cylindrical outside diameter
• Needle rolling elements
• Hex hole
• LUBRI-DISC® seal
• Eccentric configuration

Dimensions

Threads	5/8-18
Roller Diameter (in)	1.625 in
Bushing Diameter (in)	0.875 in
Minimum Thread Length (in)	0.75 in
Stud Diameter (in)	0.625 in
Lubrication Fitting Size (in)	0.1875 in
Lubrication Fitting Size (mm)	0.1875 mm
Stud Length (in)	1.5 in
Roller Width (in)	0.875 in
Hex Socket (in)	0.3125 in
Eccentricity (in)	0.03 in
Weight (kg)	0.29 kg

Technical Specifications

Limiting Speed	2,350
Rolling Element	Needle Roller - Full Complement
Hex/Slot	Hex Hole
O.D. Configuration	Cylindrical
Adjustment	Eccentric Bushing
Dynamic Radial Rating	4,840
Sealing	Sealed
Series	Inch CAMROL®
Material	Bearing Steel, Black Oxide Finish
Stud Type	Standard Stud with Eccentric Bushing
Dynamic Load Rating (lb)	4,840 lb
Tolerance Class	P0 Equivalent
Platform	CAMROL®
Static Load Rating	5,640
Roller Shape	Cylindrical
Lubrication Hole Location	Stud side
Clamping Torque (in-lbf)	650 lbs
Ability to Relubricate	Yes

General Specifications

UPC	726166036188
Weight	0.65 LB
Packaged Length	1.68 IN
Packaged Width	1.68 IN
Packaged Height	2.62 IN
HTC	8482.40.0000
Country of Origin	Mexico
