• Stud type cam follower
• Cylindrical outside diameter
• Needle rolling elements
• Slot hole
• Eccentric configuration

Dimensions

Threads	3/4-16
Roller Diameter (in)	1.75 in
Lubrication Fitting Size (in)	0.1875 in
Roller Width (in)	1 in
Eccentricity (in)	0.03 in
Stud Length (in)	1.75 in
Stud Diameter (in)	0.75 in
Bushing Diameter (in)	1 in
Lubrication Fitting Size (mm)	0.1875 mm
Minimum Thread Length (in)	0.88 in
Weight (kg)	0.42 kg

Technical Specifications

O.D. Configuration	Cylindrical
Hex/Slot	Screwdriver Slot
Sealing	Unsealed
Series	Inch CAMROL®
Adjustment	Eccentric Bushing
Limiting Speed	2,200
Dynamic Radial Rating	6,385
Rolling Element	Needle Roller - Full Complement
Material	Bearing Steel, Black Oxide Finish
Static Load Rating	7,920
Tolerance Class	P0 Equivalent
Roller Shape	Cylindrical
Stud Type	Standard Stud with Eccentric Bushing
Platform	CAMROL®
Dynamic Load Rating (lb)	6,385 lb
Lubrication Hole Location	Stud side
Ability to Relubricate	Yes
Clamping Torque (in-lbf)	1,250 lbs

General Specifications

UPC	726166081164
Weight	0.93 LB
Packaged Length	2.00 IN
Packaged Width	2.00 IN
Packaged Height	2.87 IN
HTC	8482.40.0000
Country of Origin	Mexico
