• Stud type cam follower
• Cylindrical outside diameter
• Needle rolling elements
• Hex hole
• LUBRI-DISC® seal
• Eccentric configuration

Dimensions

Threads	10-32
Roller Diameter (in)	0.5 in
Bushing Diameter (in)	0.25 in
Stud Diameter (in)	0.19 in
Roller Width (in)	0.375 in
Minimum Thread Length (in)	0.25 in
Bushing Length (in)	0.375 in
Eccentricity (in)	0.01 in
Hex Socket (in)	0.125 in
Stud Length (in)	0.625 in
Weight (kg)	0.02 kg

Technical Specifications

Rolling Element	Needle Roller - Full Complement
Dynamic Radial Rating	680
Hex/Slot	Hex Hole
O.D. Configuration	Cylindrical
Limiting Speed	11,500
Sealing	Sealed
Adjustment	Eccentric Bushing
Series	Inch CAMROL®
Material	Bearing Steel, Black Oxide Finish
Roller Shape	Cylindrical
Stud Type	Standard Stud with Eccentric Bushing
Tolerance Class	P0 Equivalent
Static Load Rating	790
Dynamic Load Rating (lb)	680 lb
Platform	CAMROL®
Lubrication Hole Location	Stud side
Ability to Relubricate	No
Clamping Torque (in-lbf)	15 lbs

General Specifications

UPC	726166029876
Weight	0.04 LB
Packaged Length	1.75 IN
Packaged Width	1.00 IN
Packaged Height	1.75 IN
HTC	8482.40.0000
Country of Origin	Mexico
