• Stud type cam follower
• Cylindrical outside diameter
• Needle rolling elements
• Hex hole
• LUBRI-DISC® seal
• Eccentric configuration

Dimensions

Threads	1/2-20
Roller Diameter (in)	1.25 in
Bushing Diameter (in)	0.687 in
Minimum Thread Length (in)	0.63 in
Lubrication Fitting Size (mm)	0.1875 mm
Hex Socket (in)	0.25 in
Stud Diameter (in)	0.5 in
Eccentricity (in)	0.03 in
Roller Width (in)	0.75 in
Stud Length (in)	1.25 in
Bushing Length (in)	0.625 in
Lubrication Fitting Size (in)	0.1875 in
Weight (kg)	0.15 kg

Technical Specifications

Rolling Element	Needle Roller - Full Complement
Adjustment	Eccentric Bushing
Sealing	Sealed
Hex/Slot	Hex Hole
Dynamic Radial Rating	3,930
Series	Inch CAMROL®
Limiting Speed	3,100
O.D. Configuration	Cylindrical
Material	Bearing Steel, Black Oxide Finish
Stud Type	Standard Stud with Eccentric Bushing
Tolerance Class	P0 Equivalent
Static Load Rating	2,300
Roller Shape	Cylindrical
Platform	CAMROL®
Dynamic Load Rating (lb)	3,930 lb
Clamping Torque (in-lbf)	350 lbs
Ability to Relubricate	Yes

General Specifications

UPC	726166034511
Weight	0.33 LB
Packaged Length	7.75 IN
Packaged Width	3.56 IN
Packaged Height	2.37 IN
HTC	8482.40.0000
Country of Origin	Mexico
