• Stud type cam follower
• Cylindrical outside diameter
• Needle rolling elements
• Hex hole
• LUBRI-DISC® seal

Dimensions

Threads	1 1/4-12
Roller Diameter (in)	3 in
Stud Diameter (in)	1.25 in
Lubrication Fitting Size (in)	0.25 in
Lubrication Fitting Size (mm)	0.25 mm
Hex Socket (in)	0.75 in
Roller Width (in)	1.75 in
Minimum Thread Length (in)	1.25 in
Stud Length (in)	2.5 in
Weight (kg)	1.83 kg

Technical Specifications

Limiting Speed	950
Adjustment	None
Hex/Slot	Hex Hole
Rolling Element	Needle Roller - Full Complement
O.D. Configuration	Cylindrical
Dynamic Radial Rating	15,720
Sealing	Sealed
Series	Inch CAMROL®
Material	Bearing Steel, Black Oxide Finish
Stud Type	Standard Stud
Tolerance Class	P0 Equivalent
Static Load Rating	18,000
Roller Shape	Cylindrical
Platform	CAMROL®
Dynamic Load Rating (lb)	15,720 lb
Ability to Relubricate	Yes
Clamping Torque (in-lbf)	3,450 lbs

General Specifications

UPC	726166039134
Weight	4.04 LB
Packaged Length	3.25 IN
Packaged Width	3.25 IN
Packaged Height	4.50 IN
HTC	8482.40.0000
Country of Origin	Mexico
