• Stud type cam follower
• Cylindrical outside diameter
• Needle rolling elements
• Hex hole
• LUBRI-DISC® seal

Dimensions

Threads	3/8-24
Roller Diameter (in)	0.75 in
Lubrication Fitting Size (in)	0.1875 in
Roller Width (in)	0.5 in
Minimum Thread Length (in)	0.38 in
Stud Length (in)	0.875 in
Lubrication Fitting Size (mm)	0.1875 mm
Oil Hole Diameter (in)	0.094 in
Stud Diameter (in)	0.375 in
Hex Socket (in)	0.1875 in
Oil Hole Center (in)	0.25 in
Weight (kg)	0.04 kg

Technical Specifications

Limiting Speed	6,400
Adjustment	None
O.D. Configuration	Cylindrical
Rolling Element	Needle Roller - Full Complement
Sealing	Sealed
Dynamic Radial Rating	1,660
Hex/Slot	Hex Hole
Series	Inch CAMROL®
Material	Bearing Steel, Black Oxide Finish
Static Load Rating	1,500
Dynamic Load Rating (lb)	1,660 lb
Stud Type	Standard Stud
Platform	CAMROL®
Tolerance Class	P0 Equivalent
Roller Shape	Cylindrical
Clamping Torque (in-lbf)	95 lbs
Ability to Relubricate	Yes

General Specifications

UPC	726166031923
Weight	0.09 LB
Packaged Length	1.75 IN
Packaged Width	1.00 IN
Packaged Height	1.75 IN
HTC	8482.40.0000
Country of Origin	Mexico
