• Stud type cam follower
• Cylindrical outside diameter
• Needle rolling elements
• Hex hole
• LUBRI-DISC® seal
• Corrosion resistant

Dimensions

Threads	3/8-24
Roller Diameter (in)	0.75 in
Stud Length (in)	0.875 in
Hex Socket (in)	0.1875 in
Oil Hole Center (in)	0.25 in
Roller Width (in)	0.5 in
Minimum Thread Length (in)	0.38 in
Lubrication Fitting Size (mm)	0.1875 mm
Oil Hole Diameter (in)	0.094 in
Lubrication Fitting Size (in)	0.1875 in
Stud Diameter (in)	0.375 in
Weight (kg)	0.03 kg

Technical Specifications

Series	CRES CAMROL®
Sealing	Sealed
Rolling Element	Needle Roller - Full Complement
Limiting Speed	6,400
Dynamic Radial Rating	1,500
Adjustment	None
Hex/Slot	Hex Hole
O.D. Configuration	Cylindrical
Material	440C Stainless Steel
Static Load Rating	1,580
Tolerance Class	P0 Equivalent
Dynamic Load Rating (lb)	1,490 lb
Stud Type	Standard Stud
Platform	CAMROL®
Roller Shape	Cylindrical
Clamping Torque (in-lbf)	95 lbs
Ability to Relubricate	Yes

General Specifications

UPC	726166118228
Weight	0.07 LB
Packaged Length	1.75 IN
Packaged Width	1.00 IN
Packaged Height	1.75 IN
HTC	8482.40.0000
Country of Origin	Mexico
