• Stud type cam follower
• Cylindrical outside diameter
• Needle rolling elements
• Slot hole
• LUBRI-DISC® seal

Dimensions

Threads	3/8-24
Roller Diameter (in)	0.75 in
Minimum Thread Length (in)	0.38 in
Stud Diameter (in)	0.375 in
Oil Hole Center (in)	0.25 in
Stud Length (in)	0.875 in
Lubrication Fitting Size (in)	0.1875 in
Roller Width (in)	0.5 in
Oil Hole Diameter (in)	0.094 in
Lubrication Fitting Size (mm)	0.1875 mm
Weight (kg)	0.04 kg

Technical Specifications

Series	Inch CAMROL®
Rolling Element	Needle Roller - Full Complement
Limiting Speed	6,400
Hex/Slot	Screwdriver Slot
O.D. Configuration	Cylindrical
Sealing	Sealed
Adjustment	None
Dynamic Radial Rating	1,660
Material	Bearing Steel, Black Oxide Finish
Roller Shape	Cylindrical
Stud Type	Standard Stud
Static Load Rating	1,500
Dynamic Load Rating (lb)	1,660 lb
Platform	CAMROL®
Tolerance Class	P0 Equivalent
Ability to Relubricate	Yes
Clamping Torque (in-lbf)	95 lbs

General Specifications

UPC	726166031817
Weight	0.09 LB
Packaged Length	1.75 IN
Packaged Width	1.00 IN
Packaged Height	1.75 IN
HTC	8482.40.0000
Country of Origin	Mexico
