• Stud type cam follower
• Cylindrical outside diameter
• Needle rolling elements
• Slot hole

Dimensions

Threads	1 1/4-12
Roller Diameter (in)	3.25 in
Lubrication Fitting Size (mm)	0.25 mm
Roller Width (in)	1.75 in
Oil Hole Center (in)	0.625 in
Minimum Thread Length (in)	1.25 in
Lubrication Fitting Size (in)	0.25 in
Stud Length (in)	2.5 in
Stud Diameter (in)	1.25 in
Weight (kg)	2.2 kg

Technical Specifications

O.D. Configuration	Cylindrical
Adjustment	None
Limiting Speed	880
Sealing	Unsealed
Hex/Slot	Screwdriver Slot
Series	Inch CAMROL®
Dynamic Radial Rating	15,720
Rolling Element	Needle Roller - Full Complement
Material	Bearing Steel, Black Oxide Finish
Dynamic Load Rating (lb)	15,720 lb
Platform	CAMROL®
Static Load Rating	24,910
Tolerance Class	P0 Equivalent
Stud Type	Standard Stud
Roller Shape	Cylindrical
Lubrication Hole Location	Stud side
Clamping Torque (in-lbf)	3,450 lbs
Ability to Relubricate	Yes

General Specifications

UPC	726166039530
Weight	4.86 LB
Packaged Length	3.25 IN
Packaged Width	3.25 IN
Packaged Height	4.50 IN
HTC	8482.40.0000
Country of Origin	Mexico
