• Stud type cam follower
• Cylindrical outside diameter
• Needle rolling elements
• Hex hole
• LUBRI-DISC® seal
• Corrosion resistant

Dimensions

Threads	7/8-14
Roller Diameter (in)	2 in
Hex Socket (in)	0.4375 in
Roller Width (in)	1.25 in
Stud Diameter (in)	0.875 in
Lubrication Fitting Size (mm)	0.1875 mm
Stud Length (in)	2 in
Minimum Thread Length (in)	1 in
Lubrication Fitting Size (in)	0.1875 in
Weight (kg)	0.58 kg

Technical Specifications

Series	CRES CAMROL®
Limiting Speed	1,400
Adjustment	None
Hex/Slot	Hex Hole
O.D. Configuration	Cylindrical
Dynamic Radial Rating	8,200
Rolling Element	Needle Roller - Full Complement
Sealing	Sealed
Material	440C Stainless Steel
Stud Type	Standard Stud
Static Load Rating	6,750
Roller Shape	Cylindrical
Dynamic Load Rating (lb)	7,270 lb
Tolerance Class	P0 Equivalent
Platform	CAMROL®
Ability to Relubricate	Yes
Clamping Torque (in-lbf)	1,500 lbs

General Specifications

UPC	726166118525
Weight	1.28 LB
Packaged Length	2.31 IN
Packaged Width	2.31 IN
Packaged Height	3.43 IN
HTC	8482.40.0000
Country of Origin	Mexico
