• Stud type cam follower
• Cylindrical outside diameter
• Needle rolling elements
• Slot hole

Dimensions

Threads	1-14
Roller Diameter (in)	2.5 in
Lubrication Fitting Size (mm)	0.1875 mm
Roller Width (in)	1.5 in
Lubrication Fitting Size (in)	0.1875 in
Minimum Thread Length (in)	1.13 in
Stud Length (in)	2.25 in
Oil Hole Center (in)	0.5625 in
Stud Diameter (in)	1 in
Weight (kg)	1.15 kg

Technical Specifications

O.D. Configuration	Cylindrical
Limiting Speed	1,100
Sealing	Unsealed
Hex/Slot	Screwdriver Slot
Dynamic Radial Rating	11,720
Series	Inch CAMROL®
Rolling Element	Needle Roller - Full Complement
Adjustment	None
Material	Bearing Steel, Black Oxide Finish
Stud Type	Standard Stud
Roller Shape	Cylindrical
Dynamic Load Rating (lb)	11,720 lb
Static Load Rating	16,450
Tolerance Class	P0 Equivalent
Platform	CAMROL®
Lubrication Hole Location	Stud side
Ability to Relubricate	Yes
Clamping Torque (in-lbf)	2,250 lbs

General Specifications

UPC	726166038212
Weight	2.54 LB
Packaged Length	2.81 IN
Packaged Width	2.81 IN
Packaged Height	3.93 IN
HTC	8482.40.0000
Country of Origin	Mexico
