• Stud type cam follower
• Cylindrical outside diameter
• Needle rolling elements
• Hex hole

Dimensions

Threads	1-14
Roller Diameter (in)	2.5 in
Lubrication Fitting Size (mm)	0.1875 mm
Roller Width (in)	1.5 in
Stud Diameter (in)	1 in
Minimum Thread Length (in)	1.13 in
Lubrication Fitting Size (in)	0.1875 in
Stud Length (in)	2.25 in
Hex Socket (in)	0.5 in
Weight (kg)	1.14 kg

Technical Specifications

Limiting Speed	1,100
Rolling Element	Needle Roller - Full Complement
Adjustment	None
Sealing	Unsealed
Hex/Slot	Hex Hole
Dynamic Radial Rating	11,720
O.D. Configuration	Cylindrical
Series	Inch CAMROL®
Material	Bearing Steel, Black Oxide Finish
Tolerance Class	P0 Equivalent
Stud Type	Standard Stud
Roller Shape	Cylindrical
Static Load Rating	10,300
Dynamic Load Rating (lb)	11,720 lb
Platform	CAMROL®
Ability to Relubricate	Yes
Clamping Torque (in-lbf)	2,250 lbs

General Specifications

UPC	726166038243
Weight	2.52 LB
Packaged Length	2.81 IN
Packaged Width	2.81 IN
Packaged Height	3.93 IN
HTC	8482.40.0000
Country of Origin	Mexico
