• Stud type cam follower
• Cylindrical outside diameter
• Needle rolling elements
• Hex hole
• LUBRI-DISC® seal
• Corrosion resistant

Dimensions

Threads	5/8-18
Roller Diameter (in)	1.625 in
Roller Width (in)	0.875 in
Minimum Thread Length (in)	0.75 in
Stud Diameter (in)	0.625 in
Lubrication Fitting Size (in)	0.1875 in
Stud Length (in)	1.5 in
Lubrication Fitting Size (mm)	0.1875 mm
Hex Socket (in)	0.3125 in
Weight (kg)	0.25 kg

Technical Specifications

Sealing	Sealed
Limiting Speed	2,350
Rolling Element	Needle Roller - Full Complement
Adjustment	None
Dynamic Radial Rating	4,000
Series	CRES CAMROL®
Hex/Slot	Hex Hole
O.D. Configuration	Cylindrical
Material	440C Stainless Steel
Tolerance Class	P0 Equivalent
Stud Type	Standard Stud
Platform	CAMROL®
Static Load Rating	4,400
Roller Shape	Cylindrical
Dynamic Load Rating (lb)	4,350 lb
Ability to Relubricate	Yes
Clamping Torque (in-lbf)	650 lbs

General Specifications

UPC	726166118389
Weight	0.56 LB
Packaged Length	1.68 IN
Packaged Width	1.68 IN
Packaged Height	2.62 IN
HTC	8482.40.0000
Country of Origin	Mexico
