• Stud type cam follower
• Cylindrical outside diameter
• Needle rolling elements
• Slot hole
• LUBRI-DISC® seal

Dimensions

Threads	5/8-18
Roller Diameter (in)	1.625 in
Stud Length (in)	1.5 in
Minimum Thread Length (in)	0.75 in
Stud Diameter (in)	0.625 in
Lubrication Fitting Size (in)	0.1875 in
Lubrication Fitting Size (mm)	0.1875 mm
Roller Width (in)	0.875 in
Oil Hole Center (in)	0.375 in
Weight (kg)	0.27 kg

Technical Specifications

Adjustment	None
O.D. Configuration	Cylindrical
Limiting Speed	2,350
Hex/Slot	Screwdriver Slot
Sealing	Sealed
Series	Inch CAMROL®
Rolling Element	Needle Roller - Full Complement
Dynamic Radial Rating	4,840
Material	Bearing Steel, Black Oxide Finish
Stud Type	Standard Stud
Roller Shape	Cylindrical
Dynamic Load Rating (lb)	4,840 lb
Tolerance Class	P0 Equivalent
Static Load Rating	5,640
Platform	CAMROL®
Lubrication Hole Location	Stud side
Clamping Torque (in-lbf)	650 lbs
Ability to Relubricate	Yes

General Specifications

UPC	726166036119
Weight	0.60 LB
Packaged Length	1.50 IN
Packaged Width	1.75 IN
Packaged Height	2.18 IN
HTC	8482.40.0000
Country of Origin	Mexico
