• Stud type cam follower
• Cylindrical outside diameter
• Needle rolling elements
• Slot hole

Dimensions

Threads	3/4-16
Roller Diameter (in)	1.75 in
Lubrication Fitting Size (in)	0.1875 in
Stud Length (in)	1.75 in
Minimum Thread Length (in)	0.88 in
Lubrication Fitting Size (mm)	0.1875 mm
Roller Width (in)	1 in
Stud Diameter (in)	0.75 in
Oil Hole Center (in)	0.4375 in
Weight (kg)	0.39 kg

Technical Specifications

Rolling Element	Needle Roller - Full Complement
Series	Inch CAMROL®
Sealing	Unsealed
Hex/Slot	Screwdriver Slot
Dynamic Radial Rating	6,385
Adjustment	None
Limiting Speed	2,200
O.D. Configuration	Cylindrical
Material	Bearing Steel, Black Oxide Finish
Static Load Rating	7,920
Stud Type	Standard Stud
Tolerance Class	P0 Equivalent
Roller Shape	Cylindrical
Platform	CAMROL®
Dynamic Load Rating (lb)	6,385 lb
Lubrication Hole Location	Stud side
Clamping Torque (in-lbf)	1,250 lbs
Ability to Relubricate	Yes

General Specifications

UPC	726166036393
Weight	0.87 LB
Packaged Length	2.00 IN
Packaged Width	2.00 IN
Packaged Height	2.87 IN
HTC	8482.40.0000
Country of Origin	Mexico
