• Stud type cam follower
• Cylindrical outside diameter
• Needle rolling elements
• Hex hole
• LUBRI-DISC® seal
• Corrosion resistant

Dimensions

Threads	3/4-16
Roller Diameter (in)	1.75 in
Roller Width (in)	1 in
Stud Diameter (in)	0.75 in
Lubrication Fitting Size (in)	0.1875 in
Lubrication Fitting Size (mm)	0.1875 mm
Minimum Thread Length (in)	0.88 in
Oil Hole Center (in)	0.4375 in
Stud Length (in)	1.75 in
Hex Socket (in)	0.3125 in
Weight (kg)	0.38 kg

Technical Specifications

Dynamic Radial Rating	6,000
Adjustment	None
Rolling Element	Needle Roller - Full Complement
Series	CRES CAMROL®
Hex/Slot	Hex Hole
Limiting Speed	2,200
O.D. Configuration	Cylindrical
Sealing	Sealed
Material	440C Stainless Steel
Static Load Rating	5,550
Stud Type	Standard Stud
Tolerance Class	P0 Equivalent
Platform	CAMROL®
Dynamic Load Rating (lb)	5,730 lb
Roller Shape	Cylindrical
Lubrication Hole Location	Stud side
Clamping Torque (in-lbf)	1,250 lbs
Ability to Relubricate	Yes

General Specifications

UPC	726166118419
Weight	0.83 LB
Packaged Length	2.00 IN
Packaged Width	2.00 IN
Packaged Height	2.87 IN
HTC	8482.40.0000
Country of Origin	Mexico
