• Stud type cam follower
• Cylindrical outside diameter
• Needle rolling elements
• Slot hole
• LUBRI-DISC® seal

Dimensions

Threads	10-32
Roller Diameter (in)	0.5 in
Stud Length (in)	0.625 in
Minimum Thread Length (in)	0.25 in
Stud Diameter (in)	0.19 in
Lubrication Fitting Size (mm)	0.125 mm
Lubrication Fitting Size (in)	0.125 in
Roller Width (in)	0.375 in
Weight (kg)	0.02 kg

Technical Specifications

O.D. Configuration	Cylindrical
Hex/Slot	Screwdriver Slot
Series	Inch CAMROL®
Rolling Element	Needle Roller - Full Complement
Sealing	Sealed
Adjustment	None
Dynamic Radial Rating	680
Limiting Speed	11,500
Material	Bearing Steel, Black Oxide Finish
Platform	CAMROL®
Tolerance Class	P0 Equivalent
Dynamic Load Rating (lb)	680 lb
Stud Type	Standard Stud
Static Load Rating	790
Roller Shape	Cylindrical
Lubrication Hole Location	Stud side
Clamping Torque (in-lbf)	15 lbs
Ability to Relubricate	Yes

General Specifications

UPC	726166029463
Weight	0.04 LB
Packaged Length	1.75 IN
Packaged Width	1.00 IN
Packaged Height	1.75 IN
HTC	8482.40.0000
Country of Origin	Mexico
