• Stud type cam follower
• Cylindrical outside diameter
• Needle rolling elements
• Slot hole

Dimensions

Threads	7/16-20
Roller Diameter (in)	1.125 in
Oil Hole Diameter (in)	0.094 in
Roller Width (in)	0.625 in
Lubrication Fitting Size (mm)	0.1875 mm
Minimum Thread Length (in)	0.5 in
Stud Diameter (in)	0.4375 in
Stud Length (in)	1 in
Oil Hole Center (in)	0.25 in
Lubrication Fitting Size (in)	0.1875 in
Weight (kg)	0.1 kg

Technical Specifications

O.D. Configuration	Cylindrical
Limiting Speed	3,400
Sealing	Unsealed
Rolling Element	Needle Roller - Full Complement
Hex/Slot	Screwdriver Slot
Adjustment	None
Series	Inch CAMROL®
Dynamic Radial Rating	2,225
Material	Bearing Steel, Black Oxide Finish
Static Load Rating	3,060
Stud Type	Standard Stud
Tolerance Class	P0 Equivalent
Platform	CAMROL®
Roller Shape	Cylindrical
Dynamic Load Rating (lb)	2,225 lb
Ability to Relubricate	Yes
Clamping Torque (in-lbf)	250 lbs

General Specifications

UPC	726166033842
Weight	0.22 LB
Packaged Length	1.50 IN
Packaged Width	1.75 IN
Packaged Height	2.18 IN
HTC	8482.40.0000
Country of Origin	Mexico
