• Yoke type cam follower
• Crowned outside diameter
• Needle rolling elements
• LUBRI-DISC® seal

Dimensions

Roller Diameter (in)	3.25 in
Bore Diameter (in)	1 in
Endplate Diameter (in)	2.13 in
Roller Width (in)	1.75 in
Oil Hole Diameter (in)	0.125 in
Minimum Boss Diameter (in)	1.75 in
Overall Width (in)	1.8125 in
Weight (kg)	1.56 kg

Technical Specifications

O.D. Configuration	Cylindrical
Limiting Speed	880
Sealing	Sealed
Rolling Element	Needle Roller - Full Complement
Series	Inch CAMROL®
Material	Bearing Steel, Black Oxide Finish
Dynamic Load Rating (lb)	15,720 lb
Platform	CAMROL®
Roller Shape	Crowned
Static Load Rating	49,820
Tolerance Class	P0
Lubrication Hole Location	Inner Ring
Roller Material	Chrome Steel
Adjustment	None
Enclosure	2 Seals
Operating Temperature Range (F)	-20 to 250 °F °F
Ability to Relubricate	Yes

General Specifications

UPC	726166058111
Weight	3.45 LB
Packaged Length	3.62 IN
Packaged Width	2.12 IN
Packaged Height	3.62 IN
HTC	8482.40.0000
Country of Origin	Mexico
