• Stud type cam follower
• Crowned outside diameter
• Needle rolling elements
• Hex hole
• LUBRI-DISC® seal
• Eccentric configuration

Dimensions

Crown Radius	10
Threads	3/8-24
Roller Diameter (in)	0.875 in
Hex Socket (in)	0.1875 in
Minimum Thread Length (in)	0.38 in
Lubrication Fitting Size (in)	0.1875 in
Bushing Length (in)	0.5 in
Stud Diameter (in)	0.375 in
Eccentricity (in)	0.015 in
Roller Width (in)	0.5 in
Bushing Diameter (in)	0.5 in
Lubrication Fitting Size (mm)	0.1875 mm
Stud Length (in)	0.875 in
Weight (kg)	0.05 kg

Technical Specifications

Dynamic Radial Rating	1,660
Limiting Speed	5,400
O.D. Configuration	Crowned
Series	Inch CAMROL®
Hex/Slot	Hex Hole
Adjustment	Eccentric Bushing
Rolling Element	Needle Roller - Full Complement
Sealing	Sealed
Material	Bearing Steel, Black Oxide Finish
Dynamic Load Rating (lb)	1,660 lb
Platform	CAMROL®
Static Load Rating	1,500
Stud Type	Standard Stud with Eccentric Bushing
Roller Shape	Crowned
Tolerance Class	P0 Equivalent
Clamping Torque (in-lbf)	95 lbs
Ability to Relubricate	Yes

General Specifications

UPC	726166032913
Weight	0.11 LB
Packaged Length	1.75 IN
Packaged Width	1.00 IN
Packaged Height	1.75 IN
HTC	8482.40.0000
Country of Origin	Mexico
