• Stud type cam follower
• Crowned outside diameter
• Needle rolling elements
• Hex hole
• LUBRI-DISC® seal
• Eccentric configuration

Dimensions

Threads	3/8-24
Crown Radius	10
Roller Diameter (in)	0.75 in
Bushing Diameter (in)	0.5 in
Lubrication Fitting Size (in)	0.1875 in
Lubrication Fitting Size (mm)	0.1875 mm
Eccentricity (in)	0.015 in
Bushing Length (in)	0.5 in
Roller Width (in)	0.5 in
Stud Diameter (in)	0.375 in
Hex Socket (in)	0.1875 in
Stud Length (in)	0.875 in
Minimum Thread Length (in)	0.38 in
Weight (kg)	0.05 kg

Technical Specifications

Rolling Element	Needle Roller - Full Complement
Adjustment	Eccentric Bushing
Series	Inch CAMROL®
Sealing	Sealed
Hex/Slot	Hex Hole
Limiting Speed	6,400
O.D. Configuration	Crowned
Dynamic Radial Rating	1,660
Material	Bearing Steel, Black Oxide Finish
Platform	CAMROL®
Static Load Rating	2,065
Stud Type	Standard Stud with Eccentric Bushing
Dynamic Load Rating (lb)	1,660 lb
Roller Shape	Crowned
Tolerance Class	P0 Equivalent
Lubrication Hole Location	Stud side
Clamping Torque (in-lbf)	95 lbs
Ability to Relubricate	Yes

General Specifications

UPC	726166032388
Weight	0.10 LB
Packaged Length	1.75 IN
Packaged Width	1.00 IN
Packaged Height	1.75 IN
HTC	8482.40.0000
Country of Origin	Mexico
