• Stud type cam follower
• Crowned outside diameter
• Needle rolling elements
• Hex hole
• LUBRI-DISC® seal

Dimensions

Crown Radius	10
Threads	3/8-24
Roller Diameter (in)	0.75 in
Lubrication Fitting Size (mm)	0.1875 mm
Lubrication Fitting Size (in)	0.1875 in
Stud Length (in)	0.875 in
Minimum Thread Length (in)	0.38 in
Oil Hole Center (in)	0.25 in
Hex Socket (in)	0.1875 in
Oil Hole Diameter (in)	0.094 in
Stud Diameter (in)	0.375 in
Roller Width (in)	0.5 in
Weight (kg)	0.04 kg

Technical Specifications

O.D. Configuration	Crowned
Hex/Slot	Hex Hole
Adjustment	None
Dynamic Radial Rating	1,660
Sealing	Sealed
Limiting Speed	6,400
Series	Inch CAMROL®
Rolling Element	Needle Roller - Full Complement
Material	Bearing Steel, Black Oxide Finish
Platform	CAMROL®
Stud Type	Standard Stud
Tolerance Class	P0 Equivalent
Static Load Rating	2,065
Dynamic Load Rating (lb)	1,660 lb
Roller Shape	Crowned
Lubrication Hole Location	Stud side
Clamping Torque (in-lbf)	95 lbs
Ability to Relubricate	Yes

General Specifications

UPC	726166032333
Weight	0.09 LB
Packaged Length	1.75 IN
Packaged Width	1.00 IN
Packaged Height	1.75 IN
HTC	8482.40.0000
Country of Origin	Mexico
