• Stud type cam follower
• Crowned outside diameter
• Needle rolling elements
• Slot hole
• LUBRI-DISC® seal

Dimensions

Crown Radius	10
Threads	3/8-24
Roller Diameter (in)	0.75 in
Lubrication Fitting Size (in)	0.1875 in
Lubrication Fitting Size (mm)	0.1875 mm
Stud Diameter (in)	0.375 in
Oil Hole Center (in)	0.25 in
Stud Length (in)	0.875 in
Minimum Thread Length (in)	0.38 in
Oil Hole Diameter (in)	0.094 in
Roller Width (in)	0.5 in
Weight (kg)	0.04 kg

Technical Specifications

Adjustment	None
Hex/Slot	Screwdriver Slot
Limiting Speed	6,400
Series	Inch CAMROL®
Dynamic Radial Rating	1,660
Rolling Element	Needle Roller - Full Complement
O.D. Configuration	Crowned
Sealing	Sealed
Material	Bearing Steel, Black Oxide Finish
Dynamic Load Rating (lb)	1,660 lb
Tolerance Class	P0 Equivalent
Static Load Rating	2,065
Stud Type	Standard Stud
Platform	CAMROL®
Roller Shape	Crowned
Lubrication Hole Location	Stud side
Clamping Torque (in-lbf)	95 lbs
Ability to Relubricate	Yes

General Specifications

UPC	726166032272
Weight	0.09 LB
Packaged Length	1.75 IN
Packaged Width	1.00 IN
Packaged Height	1.75 IN
HTC	8482.40.0000
Country of Origin	Mexico
