• Stud type cam follower
• Crowned outside diameter
• Needle rolling elements
• Slot hole
• LUBRI-DISC® seal

Dimensions

Threads	7/16-20
Crown Radius	12
Roller Diameter (in)	1 in
Lubrication Fitting Size (in)	0.1875 in
Oil Hole Center (in)	0.25 in
Stud Length (in)	1 in
Stud Diameter (in)	0.4375 in
Roller Width (in)	0.625 in
Lubrication Fitting Size (mm)	0.1875 mm
Oil Hole Diameter (in)	0.094 in
Minimum Thread Length (in)	0.5 in
Weight (kg)	0.07 kg

Technical Specifications

Limiting Speed	4,800
Adjustment	None
Rolling Element	Needle Roller - Full Complement
O.D. Configuration	Crowned
Sealing	Sealed
Hex/Slot	Screwdriver Slot
Dynamic Radial Rating	2,225
Series	Inch CAMROL®
Material	Bearing Steel, Black Oxide Finish
Roller Shape	Crowned
Tolerance Class	P0 Equivalent
Platform	CAMROL®
Dynamic Load Rating (lb)	2,225 lb
Static Load Rating	3,060
Stud Type	Standard Stud
Clamping Torque (in-lbf)	250 lbs
Ability to Relubricate	Yes

General Specifications

UPC	726166033545
Weight	0.15 LB
Packaged Length	1.75 IN
Packaged Width	1.00 IN
Packaged Height	1.75 IN
HTC	8482.40.0000
Country of Origin	Mexico
