• Stud type cam follower
• Crowned outside diameter
• Needle rolling elements
• Hex hole
• LUBRI-DISC® seal

Dimensions

Threads	3/4-16
Crown Radius	20
Roller Diameter (in)	1.875 in
Lubrication Fitting Size (in)	0.1875 in
Stud Length (in)	1.75 in
Oil Hole Center (in)	0.4375 in
Lubrication Fitting Size (mm)	0.1875 mm
Roller Width (in)	1 in
Stud Diameter (in)	0.75 in
Minimum Thread Length (in)	0.88 in
Hex Socket (in)	0.3125 in
Weight (kg)	0.42 kg

Technical Specifications

Rolling Element	Needle Roller - Full Complement
Sealing	Sealed
Limiting Speed	2,000
Hex/Slot	Hex Hole
Dynamic Radial Rating	6,385
Adjustment	None
Series	Inch CAMROL®
O.D. Configuration	Crowned
Material	Bearing Steel, Black Oxide Finish
Tolerance Class	P0 Equivalent
Static Load Rating	7,920
Roller Shape	Crowned
Platform	CAMROL®
Stud Type	Standard Stud
Dynamic Load Rating (lb)	6,385 lb
Lubrication Hole Location	Stud side
Ability to Relubricate	Yes
Clamping Torque (in-lbf)	1,250 lbs

General Specifications

UPC	726166037086
Weight	0.93 LB
Packaged Length	2.00 IN
Packaged Width	2.00 IN
Packaged Height	2.87 IN
HTC	8482.40.0000
Country of Origin	Mexico
