• Stud type cam follower
• Cylindrical outside diameter
• Non-metallic bushing
• Hex hole
• LUBRI-DISC® seal

Dimensions

Threads	7/8-14
Roller Diameter (in)	2 in
Roller Width (in)	1.25 in
Lubrication Fitting Size (mm)	0.1875 mm
Stud Diameter (in)	0.875 in
Oil Hole Center (in)	0.5 in
Hex Socket (in)	0.4375 in
Lubrication Fitting Size (in)	0.1875 in
Stud Length (in)	2 in
Minimum Thread Length (in)	1 in
Weight (kg)	0.55 kg

Technical Specifications

Sealing	Sealed
Series	Inch CAMROL®
Adjustment	None
O.D. Configuration	Cylindrical
Hex/Slot	Hex Hole
Rolling Element	Selflube Bushing
Material	Bearing Steel, Black Oxide Finish
Stud Type	Standard Stud
Tolerance Class	P0 Equivalent
Platform	CAMROL®
Roller Shape	Cylindrical
Lubrication Hole Location	Stud side
Clamping Torque (in-lbf)	1,500 lbs
Ability to Relubricate	Yes

General Specifications

UPC	726166037826
Weight	1.22 LB
Packaged Length	2.31 IN
Packaged Width	2.31 IN
Packaged Height	3.43 IN
HTC	8482.80.0080
Country of Origin	Mexico
