• Stud type cam follower
• Cylindrical outside diameter
• Non-metallic bushing
• Hex hole
• LUBRI-DISC® seal

Dimensions

Threads	1-14
Roller Diameter (in)	2.5 in
Roller Width (in)	1.5 in
Minimum Thread Length (in)	1.13 in
Lubrication Fitting Size (in)	0.1875 in
Stud Length (in)	2.25 in
Hex Socket (in)	0.5 in
Lubrication Fitting Size (mm)	0.1875 mm
Oil Hole Center (in)	0.5625 in
Stud Diameter (in)	1 in
Weight (kg)	1.02 kg

Technical Specifications

Sealing	Sealed
Series	Inch CAMROL®
Hex/Slot	Hex Hole
Rolling Element	Selflube Bushing
O.D. Configuration	Cylindrical
Adjustment	None
Material	Bearing Steel, Black Oxide Finish
Platform	CAMROL®
Roller Shape	Cylindrical
Stud Type	Standard Stud
Tolerance Class	P0 Equivalent
Lubrication Hole Location	Stud side
Ability to Relubricate	Yes
Clamping Torque (in-lbf)	2,250 lbs

General Specifications

UPC	726166038700
Weight	2.25 LB
Packaged Length	2.81 IN
Packaged Width	2.81 IN
Packaged Height	3.93 IN
HTC	8482.80.0080
Country of Origin	Mexico
