• 2 15/16" Mounted Ball Bearing, Standard Duty, Cast Iron Protected Screw Take-up Block, Setscrew Locking, Clearance Seal, Steel Retainers, Special Grease, C4 Clearance

Dimensions

Bore Diameter (in)	2.9375 in
Overall Height (in)	7.5 in
Overall Length (in)	10 in
Length Through Bore (in)	2.88 in
Slot Width (in)	4.14 in
Overall Width (in)	5.12 in
Slot Spacing (in)	5.69 in
Centerline to Outermost Bearing Face (in)	1.81 in

Technical Specifications

Housing Style	Take-Up Block
Housing Type	Take-Up Block
Seal Type	STEEL CLEARANCE SEAL
Cage Material	Steel
Housing Color	Black
Outer Ring Land Profile	Standard
Bore Shape	Straight
Rolling Element	Ball Bearing
Housing Construction	One Piece
Misalignment Type	Static Only
Locking Collar Outside Diameter (in)	4.62 in
Ability to Relubricate	Yes
Max Operating Temperature (F)	300 °F
Max Operating Temperature (C)	150 °C
Grease Fitting Thread Size	1/8 NPT
Lubricant	MOBIL MOBILITH SHC460
Shaft Locking Type	Set Screw
Fixed vs. Expansion	Fixed
Bearing Brand	LINK-BELT 200 SERIES BALL
Vibration Frequency Roller Spin	0.0475 cps
Maximum Speed (RPM)	3300 rpm
Housing Material	Cast Iron
Vibration Frequency Outer Ring Defect	0.0760 cps
Bearing Insert Material	52100 Bearing Steel
Radial Clearance	C4 INCREASED
Bearing Type	Standard Duty
Misalignment Capability	±1.5° Misalignment - Static Only
Inner Ring Outside Diameter (in)	3.624 in
Dynamic Load Rating (lb)	15,080 lb
Vibration Frequency Fundamental Train	0.0068 cps
Vibration Frequency Inner Ring Defect	0.1073 cps
Insert	UG247JHL18WC4
Locking Device Kit	U2475S
Cage Type	Ball Riding Retainer
Housing Coating	Powder Coated
End Cap Available	No
Static Load Rating (lb)	11,100 lb
Size Code	215

General Specifications

UPC	793699754841
Weight	23.80 LB
Packaged Length	9.75 IN
Packaged Width	5.75 IN
Packaged Height	9.75 IN
HTC	8483204040
Country of Origin	Mexico
