Dimensions

Slot Length (in)	1.63 in
Base Width (in)	3.44 in
Base to Center Height (in)	3.75 in
Overall Width (in)	4.38 in
Locking Collar Outside Diameter (in)	4.91 in
Overall Height (in)	7.5 in
Bolt Size (in)	7/8 in
Foot Height (in)	2.25 in
Overall Length (in)	13 in
Base Length (in)	13 in
Housing Cast Face to Outermost Bearing Face (in)	0.94 in
Length Through Bore (in)	4.38 in
Expansion Capability (in)	0.38 in
Bolt Spacing (in)	10 in
Inner Ring Outside Diameter (in)	3.975 in
Centerline to Outermost Bearing Face (in)	2.66 in

Technical Specifications

Housing Color	Black
Seal Kit	B456HS
Series	Solid-housed Pillow Blocks
Seal Type	Clearance Seal
Housing Type	Pillow Block, Two Bolt
Cage Material	Steel
Static Load Rating (lb)	90,700 lb
Rolling Element	Spherical Roller
Misalignment Type	Dynamic
Fixed/Expansion	Expansion
Housing Style	Pillow Block
Housing Construction	Solid
Setscrew Torque (in-lbs)	680 in/lbs
Shaft Locking Type	Single Set Collar
Product	PEB22400
Maximum Speed (RPM)	1650 rpm
Radial Dynamic Load Capacity (lb)	62,300 lb
Housing Material	Cast Iron
Ability to Relubricate	Yes
Insert	CSEB22455HK5
Vibration Frequency Inner Ring Defect	0.1784 cps
Locking Device Kit	B456SC
Lubricant	PRESERVATIVE ONLY - NO GREASE
Vibration Frequency Fundamental Train	0.0073 cps
Max Operating Temperature (C)	107 °C
Vibration Frequency Outer Ring Defect	0.1383 cps
Max Operating Temperature (F)	225 °F
Grease Fitting Thread Size	1/8 NPT
Housing Coating	Powder Coated
Size Code	B456
Vibration Frequency Roller Spin	0.0628 cps
Expansion Lock Plug	B225728A
Misalignment Capability	±2.0° Misalignment - Dynamic

General Specifications

UPC	793699304831
Weight	40.80 LB
HTC	8483208080
Country of Origin	Mexico
