Dimensions

Bore Diameter (in)	1.1875 in
Length Through Bore (in)	2.75 in
Overall Width (in)	2.75 in
Overall Length (in)	8.25 in
Bolt Size (in)	1/2 in
Base to Center Height (in)	2.125 in
Overall Height (in)	4.25 in
Base Width (in)	2.25 in
Foot Height (in)	0.94 in
Bolt Spacing (in)	6.44 in
Centerline to Outermost Bearing Face (in)	1.98 in

Technical Specifications

Housing Style	Pillow Block
Housing Base	Semi-Solid
Wrench Style Shurlok Install Tool	N6103-SPN
Housing Type	Pillow Block, Two Bolt
Outer Ring Land Profile	Standard
Cage Material	Molded fiber glass reinforced nylon
Slot Length (in)	1.06 in
Locking Collar Outside Diameter (in)	2.16 in
Housing Color	Black
Rolling Element	Ball Bearing
Misalignment Type	Static Only
Housing Construction	One Piece
Bore Shape	Straight
Ability to Relubricate	Yes
Dynamic Load Rating (lb)	6,320 lb
Bearing Insert Material	52100 Bearing Steel
Max Operating Temperature (F)	225 °F
Expansion Capability (in)	0.19 in
Grease Fitting Thread Size	1/4-28
Housing Material	Cast Iron
Inner Ring Outside Diameter (in)	1.708 in
Maximum Speed (RPM)	8300 rpm
Base Length (in)	8.25 in
Bearing Type	Heavy Duty
Misalignment Capability	±2.0° Misalignment - Static Only
Vibration Frequency Fundamental Train	0.0063 cps
Vibration Frequency Roller Spin	0.0325 cps
Radial Clearance	C3 STANDARD
Vibration Frequency Outer Ring Defect	0.0507 cps
Impact Style Shurlok Install Tool	N6103-IMP
Size Code	319
Cage Type	Ball Riding Retainer
Expansion Lock Plug	3198B
Housing Coating	Powder Coated
Max Operating Temperature (C)	107 °C
End Cap Available	No
Shaft Locking Type	Tapered Adapter
Fixed vs. Expansion	Expansion
Static Load Rating (lb)	3,530 lb
Vibration Frequency Inner Ring Defect	0.0827 cps

General Specifications

UPC	662864628051
Weight	8.00 LB
HTC	8483208040
Country of Origin	Mexico
