• Consult Application Engineering

Dimensions

Outside Diameter (mm)	90 mm
Bore Size (mm)	35 mm

Technical Specifications

Bearing Width (mm)	23 mm
Shaft Shoulder Diameter (Ribbed Inner Ring) [Min] (mm)	52.1 mm
Mounted Clearance	SEE DESCRIPTION
Co Static Load Rating	CALL ENG lb
Outer Ring Type	Single Rib Outer Ring One Retaining Ring in I.D. (U)
Vibration Frequency Roller Spin	CALL ENG cps
Vibration Frequency Inner Ring Defect	CALL ENG cps
C Dynamic Load Rating	CALL ENG lb
Series	Unmounted Bearings
Rolling Element	Cylindrical
Retainer Type	SEE DESCRIPTION
Outer Ring and Roller Assembly Under Roller Diameter (mm)	52.34 mm
Inner Ring and Roller Assembly Over Roller Diameter (mm)	77.62 mm
Housing Shoulder Diameter (Plain Outer Ring) [Max] (mm)	81.3 mm
Inner Ring Type	Double Rib (U)
Vibration Frequency Fundamental Train	CALL ENG cps
Outer Ring Rib Inside Diameter (mm)	73.33 mm
Outer Ring Raceway Inside Diameter (mm)	77.66 mm
Series Weight	Medium (3)
Inner Ring Rib Outside Diameter (mm)	57 mm
Inner Ring Bore Radius (mm)	1.52 mm
Product	Series 1300 Unmounted Bearings Next Smaller Bearing Bore Size
Housing Shoulder Diameter (Ribbed Outer Ring) [Max] (mm)	77.5 mm
Shaft Shoulder Diameter (Plain Inner Ring) [Min] (mm)	49 mm
Vibration Frequency Outer Ring Defect	CALL ENG cps
Maximum Speed (RPM)	CALL ENG rpm
Ring Width Series	Narrow (1)
Inner Ring Raceway Outside Diameter (mm)	52.3 mm
Basic Bearing Number	1308

General Specifications

UPC	662327448455
Weight	1.73 LB
HTC	8482500000
Country of Origin	Mexico
