• Consult Application Engineering

Dimensions

Bore Size (mm)	40 mm
Outside Diameter (mm)	90 mm

Technical Specifications

Series Weight	Medium (3)
Inner Ring and Roller Assembly Over Roller Diameter (mm)	77.62 mm
Co Static Load Rating	CALL ENG lb
Inner Ring Raceway Outside Diameter (mm)	52.3 mm
Inner Ring Bore Radius (mm)	1.52 mm
Inner Ring Type	Double Rib (U)
Shaft Shoulder Diameter (Ribbed Inner Ring) [Min] (mm)	52.1 mm
Vibration Frequency Roller Spin	CALL ENG cps
Outer Ring Type	Outer Ring With Two Retaining Rings in I.D. (T)
Rolling Element	Cylindrical
Retainer Type	SEE DESCRIPTION
Inner Ring Rib Outside Diameter (mm)	57 mm
Ring Width Series	Narrow (1)
Series	Unmounted Bearings
Outer Ring Raceway Inside Diameter (mm)	77.66 mm
Vibration Frequency Inner Ring Defect	CALL ENG cps
C Dynamic Load Rating	CALL ENG lb
Basic Bearing Number	1308
Shaft Shoulder Diameter (Plain Inner Ring) [Min] (mm)	49 mm
Vibration Frequency Outer Ring Defect	CALL ENG cps
Housing Shoulder Diameter (Ribbed Outer Ring) [Max] (mm)	77.5 mm
Product	Series 1300 Unmounted Bearings Next Smaller Bearing Bore Size
Maximum Speed (RPM)	CALL ENG rpm
Housing Shoulder Diameter (Plain Outer Ring) [Max] (mm)	81.3 mm
Outer Ring and Roller Assembly Under Roller Diameter (mm)	52.34 mm
Outer Ring Rib Inside Diameter (mm)	73.33 mm
Bearing Width (mm)	23 mm
Mounted Clearance	SEE DESCRIPTION
Vibration Frequency Fundamental Train	CALL ENG cps
Bore Type	Straight

General Specifications

UPC	662327056612
Weight	1.73 LB
HTC	8482500000
Country of Origin	Mexico
