• Consult Application Engineering

Dimensions

Bore Size (mm)	35 mm
Outside Diameter (mm)	80 mm

Technical Specifications

Housing Shoulder Diameter (Plain Outer Ring) [Max] (mm)	71.4 mm
Outer Ring and Roller Assembly Under Roller Diameter (mm)	44.01 mm
Inner Ring Bore Radius (mm)	1.52 mm
Inner Ring and Roller Assembly Over Roller Diameter (mm)	62.43 mm
Product	Series 1300 Unmounted Bearings Next Smaller Bearing Bore Size
Outer Ring Rib Inside Diameter (mm)	64.46 mm
Inner Ring Raceway Outside Diameter (mm)	46.84 mm
Vibration Frequency Fundamental Train	CALL ENG cps
Outer Ring Raceway Inside Diameter (mm)	67.94 mm
Series	Unmounted Bearings
Shaft Shoulder Diameter (Plain Inner Ring) [Min] (mm)	43.7 mm
Basic Bearing Number	1307
C Dynamic Load Rating	CALL ENG lb
Vibration Frequency Inner Ring Defect	CALL ENG cps
Inner Ring Rib Outside Diameter (mm)	50.67 mm
Maximum Speed (RPM)	CALL ENG rpm
Mounted Clearance	SEE DESCRIPTION
Bore Type	Straight
Co Static Load Rating	CALL ENG lb
Bearing Width (mm)	21 mm
Inner Ring Type	Double Rib (U)
Ring Width Series	Narrow (1)
Retainer Type	SEE DESCRIPTION
Shaft Shoulder Diameter (Ribbed Inner Ring) [Min] (mm)	46.7 mm
Vibration Frequency Roller Spin	CALL ENG cps
Series Weight	Medium (3)
Outer Ring Type	Outer Ring With Two Retaining Rings in I.D. (T)
Housing Shoulder Diameter (Ribbed Outer Ring) [Max] (mm)	67.8 mm
Vibration Frequency Outer Ring Defect	CALL ENG cps
Rolling Element	Cylindrical

General Specifications

UPC	662327056582
Weight	1.27 LB
HTC	8482500000
Country of Origin	Mexico
