Dimensions

Bore Size (mm)	45 mm
Outside Diameter (mm)	100 mm

Technical Specifications

Vibration Frequency Roller Spin	CALL ENG cps
Bearing Width (mm)	31 mm
Outer Ring Rib Inside Diameter (mm)	81.48 mm
Inner Ring Raceway Outside Diameter (mm)	59.36 mm
Shaft Shoulder Diameter (Plain Inner Ring) [Min] (mm)	55.9 mm
Housing Shoulder Diameter (Ribbed Outer Ring) [Max] (mm)	85.8 mm
Vibration Frequency Inner Ring Defect	CALL ENG cps
Inner Ring Rib Outside Diameter (mm)	64.31 mm
Retainer Type	SEE DESCRIPTION
Shaft Shoulder Diameter (Ribbed Inner Ring) [Min] (mm)	59.2 mm
Outer Ring and Roller Assembly Under Roller Diameter (mm)	59.41 mm
C Dynamic Load Rating	CALL ENG lb
Rolling Element	Cylindrical
Series	Unmounted Bearings
Vibration Frequency Outer Ring Defect	CALL ENG cps
Mounted Clearance	SEE DESCRIPTION
Inner Ring Type	Double Rib (U)
Inner Ring and Roller Assembly Over Roller Diameter (mm)	86.06 mm
Housing Shoulder Diameter (Plain Outer Ring) [Max] (mm)	90.4 mm
Series Weight	Medium (3)
Vibration Frequency Fundamental Train	CALL ENG cps
Basic Bearing Number	7309
Inner Ring Bore Radius (mm)	2.03 mm
Product	Series 7300 Unmounted Bearings
Ring Width Series	Intermediate (7)
Outer Ring Raceway Inside Diameter (mm)	86.1 mm
Outer Ring Type	Single Rib Outer Ring One Retaining Ring in I.D. (U)
Co Static Load Rating	CALL ENG lb
Maximum Speed (RPM)	CALL ENG rpm

General Specifications

UPC	793699128611
Weight	2.73 LB
HTC	8482500000
Country of Origin	Mexico
