• 75 mm Cylindrical Roller Bearing with double rib inner ring, 2 retaining rings in outer ring and formed steel retainer

Dimensions

Bore Size (mm)	75 mm
Outside Diameter (mm)	130 mm

Technical Specifications

Inner Ring Rib Outside Diameter (mm)	93.85 mm
Inner Ring Bore Radius (mm)	1.52 mm
Retainer Type	SEE DESCRIPTION
Series	Unmounted Bearings
Ring Width Series	Wide (5)
Vibration Frequency Outer Ring Defect	CALL ENG cps
Outer Ring Raceway Inside Diameter (mm)	115.78 mm
Vibration Frequency Fundamental Train	CALL ENG cps
Shaft Shoulder Diameter (Ribbed Inner Ring) [Min] (mm)	88.9 mm
Rolling Element	Cylindrical
Mounted Clearance	SEE DESCRIPTION
Shaft Shoulder Diameter (Plain Inner Ring) [Min] (mm)	85.6 mm
Bearing Width (mm)	41.28 mm
Inner Ring and Roller Assembly Over Roller Diameter (mm)	115.71 mm
C Dynamic Load Rating	CALL ENG lb
Shaft Locking	DIRECT SHAFT MOUNT
Series Weight	Light (2)
Housing Shoulder Diameter (Plain Outer Ring) [Max] (mm)	120.1 mm
Basic Bearing Number	5215
Outer Ring Type	Outer Ring With Two Retaining Rings in I.D. (T)
Housing Shoulder Diameter (Ribbed Outer Ring) [Max] (mm)	115.6 mm
Inner Ring Raceway Outside Diameter (mm)	89.01 mm
Inner Ring Type	Double Rib (U)
Vibration Frequency Roller Spin	CALL ENG cps
Outer Ring and Roller Assembly Under Roller Diameter (mm)	89.09 mm
Bore Type	Straight
Product	Series 5200 Unmounted Bearings
Vibration Frequency Inner Ring Defect	CALL ENG cps
Maximum Speed (RPM)	CALL ENG rpm
Outer Ring Rib Inside Diameter (mm)	111.25 mm
Co Static Load Rating	CALL ENG lb

General Specifications

UPC	662327059224
Weight	5.18 LB
HTC	8482500000
Country of Origin	Mexico
