Dimensions

Bore Size (mm)	25 mm
Outside Diameter (mm)	52 mm

Technical Specifications

Co Static Load Rating	CALL ENG lb
Bore Type	Straight
Shaft Shoulder Diameter (Plain Inner Ring) [Min] (mm)	30.5 mm
Bearing Width (mm)	20.64 mm
Housing Shoulder Diameter (Ribbed Outer Ring) [Max] (mm)	44.7 mm
Series	Unmounted Bearings
Housing Shoulder Diameter (Plain Outer Ring) [Max] (mm)	47 mm
Series Weight	Light (2)
Basic Bearing Number	5205
Inner Ring and Roller Assembly Over Roller Diameter (mm)	44.82 mm
Vibration Frequency Outer Ring Defect	CALL ENG cps
Outer Ring Raceway Inside Diameter (mm)	44.85 mm
Outer Ring Rib Inside Diameter (mm)	42.95 mm
Shaft Shoulder Diameter (Ribbed Inner Ring) [Min] (mm)	32 mm
Maximum Speed (RPM)	CALL ENG rpm
Inner Ring Raceway Outside Diameter (mm)	32.17 mm
Vibration Frequency Inner Ring Defect	CALL ENG cps
Ring Width Series	Wide (5)
Inner Ring Bore Radius (mm)	1.02 mm
Outer Ring and Roller Assembly Under Roller Diameter (mm)	32.2 mm
Vibration Frequency Roller Spin	CALL ENG cps
Outer Ring Type	Single Rib Outer Ring One Retaining Ring in I.D. (U)
C Dynamic Load Rating	CALL ENG lb
Inner Ring Rib Outside Diameter (mm)	34.32 mm
Rolling Element	Cylindrical
Inner Ring Type	Double Rib (U)
Product	Series 5200 Unmounted Bearings
Mounted Clearance	SEE DESCRIPTION
Retainer Type	SEE DESCRIPTION
Vibration Frequency Fundamental Train	CALL ENG cps

General Specifications

UPC	662327058845
Weight	0.46 LB
HTC	8482500000
Country of Origin	Mexico
