• 65 mm Cylindrical Roller Bearing with double rib inner ring, single rib and 1 retaining ring in outer ring and no retainer - full complement

Dimensions

Bore Size (mm)	65 mm
Outside Diameter (mm)	140 mm

Technical Specifications

Co Static Load Rating	CALL ENG lb
Shaft Shoulder Diameter (Ribbed Inner Ring) [Min] (mm)	83.6 mm
Shaft Locking	DIRECT SHAFT MOUNT
Vibration Frequency Inner Ring Defect	CALL ENG cps
Vibration Frequency Outer Ring Defect	CALL ENG cps
Series	Unmounted Bearings
Vibration Frequency Fundamental Train	CALL ENG cps
Housing Shoulder Diameter (Ribbed Outer Ring) [Max] (mm)	121.2 mm
Outer Ring Type	Single Rib Outer Ring One Retaining Ring in I.D. (U)
Bore Type	Straight
Inner Ring Raceway Outside Diameter (mm)	83.68 mm
Outer Ring Raceway Inside Diameter (mm)	121.37 mm
Outer Ring Rib Inside Diameter (mm)	114.68 mm
Series Weight	Medium (3)
Basic Bearing Number	1313
Bearing Width (mm)	33 mm
C Dynamic Load Rating	CALL ENG lb
Housing Shoulder Diameter (Plain Outer Ring) [Max] (mm)	127 mm
Mounted Clearance	SEE DESCRIPTION
Inner Ring Bore Radius (mm)	2.03 mm
Inner Ring Type	Double Rib (U)
Shaft Shoulder Diameter (Plain Inner Ring) [Min] (mm)	78.7 mm
Ring Width Series	Narrow (1)
Inner Ring Rib Outside Diameter (mm)	90.7 mm
Retainer Type	SEE DESCRIPTION
Maximum Speed (RPM)	CALL ENG rpm
Outer Ring and Roller Assembly Under Roller Diameter (mm)	83.73 mm
Rolling Element	Cylindrical
Vibration Frequency Roller Spin	CALL ENG cps
Inner Ring and Roller Assembly Over Roller Diameter (mm)	121.31 mm
Product	Series 1300 Unmounted Bearings

General Specifications

UPC	662327058425
Weight	5.54 LB
HTC	8482500000
Country of Origin	Mexico
